NZXT H510 Elite - Premium Mid-Tower ATX Case PC Gaming Case - Dual-Tempered Glass Panel - Front I/O USB Type-C Port - Vertical GPU Mount - Integrated RGB Lighting - Water-Cooling Ready - Black, CA-H510E-B1
NZXT H Series H510 Elite
» MORE MODERN: USB 3.1 Gen 2-compatible USB-C connector on the front panel makes it easier than ever to connect smartphones, high-speed external storage, and the latest peripherals to your PC.
» SMART DEVICE V2: Includes two HUE 2 RGB lighting channels, and three fan channels that support 0dB modes for voltage-regulated or PWM fans.
» EXTRAORDINARILY BEAUTIFUL: The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass panels all showcase your stunning build.
» POWERED BY NZXT CAM: Use the intuitive NZXT CAM application to monitor and control your build, choosing from presets or custom controls for your RGB lighting and fans to create your dream PC
» NEW FEATURES: Front I/O USB Type-C Port, Dual Tempered Glass, Vertical GPU Mount, and two 140mm AER RGB 2 Fans (included)
» MOTHERBOARD SUPPORT: Mini-ITX, MicroATX, and ATX
Specifications
- Brand : NZXT
- Series : H Series H510 Elite
- Model : CA-H510E-B1
- Type : ATX Mid Tower
- Color : Matte Black
- Case Material : SGCC Steel / Tempered Glass
- With Power Supply : No
- Power Supply Mounted : Bottom
- Motherboard Compatibility : Micro ATX / ATX / Mini-ITX
- Side Panel Window : Yes
- LED : 2 x Integrated Aer RGB 2 140mm Fans
1 x Integrated addressable LED Strip - Dust Filters : Bottom
- Internal 3.5" Drive Bays : 2+1
- Internal 2.5" Drive Bays : 2+1
- Expansion Slots : 7+2 Vertical
- Front Ports : 1 x USB 3.0 Type-A / 1 x USB 3.1 Gen 2 Type-C / 1 x Headset Audio Jack
- Fan Options : Front: 2 x 120 or 2 x 140mm fan (2 x AER RGB 2 140mm included)
Top: 1 x 120mm or 1 x 140mm fan
Rear: 1 x 120mm fan (1 x 120mm AER F120 Case Version Included)
Fan Specs: Aer RGB 2 (140mm)
Speed: 500-1,500 RPM
Airflow: 30.39 - 91.19 CFM
Noise: 22 - 33 dBA
Air Pressure: 0.17 - 1.52mm-H2O
Bearing: Fluid Dynamic Bearing
Fan Connector 4-Pin PWM - Radiator Options : Front: 2 x 140 or 2 x 120mm with Pull
Rear: 1 x 120mm - Max GPU Length : 381 mm
- Max CPU Cooler Height : 165 mm
- Dimensions (H x W x D) : 18.11" x 8.27" x 16.85" w/ feet
17.13" x 8.27" x 16.85" w/o feet - Weight : 16.53 lbs
