Antec Dark Phantom DP501 ATX Mid Tower Gaming Case /ARGB Motherboard Sync/ Tempered Glass
Antec Dark Phantom DP501
» ARGB MINIMALISM: Sleek and sharp design for simple gaming style
» INBUILT LED CONTROLLER: Connect the 3-pin module with the motherboard for 16.8 million custom colors
» ULTIMATE THERMAL PERFORMANCE: supports up to 6 LED case fans
» HIGH WATER-COOLING CAPABILITY: Ample room for both AIO and custom loop configurations
» LED MODE I/O BUTTON: controls the colors and modes of inbuilt LED strips and other ARGB components.
» MOTHERBOARD SUPPORT: ATX, Micro-ATX
Description
- Case Specification
- Case Dimensions : 443mm x 210mm x 484mm (DxWxH)
- Form Factor : Mid Tower
- Materials : SGCC + Plastic
- Motherboard Support : ATX, Micro-ATX, ITX
- Front Access & Controls : USB3.0 x 2, MIC/AUDIO(HD), Power, Reset, Mode
- Side Panel : Tempered Glass Side Panel
- Expansion & Drive Bays
- Expansion Slots : 7
- 3.5" : 2
- 2.5" : 4
- Fan Support
- Front : 3 x 120mm or 2 x 140mm
- Top : 2 x 120mm or 2 x 140mm
- Rear : 1 x 120mm
- Included Fan(s) : 1 x 120mm in Rear
- Radiator Support
- Front : ≤ 360mm
- Top : ≤ 280mm
- Rear : ≤ 120mm
- Clearance
- MB Tray Clearance : ≤ 20mm
- Max GPU Length : ≤ 360mm
- Max CPU Cooler Height : ≤ 160mm
- Max PSU Length : ≤ 160mm
- Miscellaneous
- Dust Filters : Top / Bottom
- Net Weight : 5.57 Kgs
- Gross Weight : 6.4 Kgs
- Warranty : 2 Years
- UPC# : 0-761345-80019-8
Specifications
- Brand : Antec
- Series : Dark Phantom
- Model : DP501
- Type : ATX Mid Tower
- Color : Black
- Case Material : SPCC /Plastic
- With Power Supply : No
- Power Supply Mounted : Bottom
- Motherboard Compatibility : Micro ATX / ATX / ITX
- Side Panel Window : Yes
- Dust Filters : Top / Bottom
- Internal 3.5" Drive Bays : 2
- Internal 2.5" Drive Bays : 4
- Expansion Slots : 7
- Front Ports : 2 x USB 3.0 / Audio
- Fan Options : Front: 3 x 120mm or 2 x 140mm fan
Top: 2 x 120mm or 2 x 140mm fan
Rear: 1 x 120mm fan (Included) - Radiator Options : Front - Up to 360mm / Rear - Up to 120mm / Top - Up to 280mm
- Max GPU Length : 360 mm
- Max CPU Cooler Height : 165 mm
- Max PSU Length : 160 mm
- Dimensions (H x W x D) : 19.06" x 8.27" x 17.44"
- Weight : 12.28 lbs
